The EOS R5 Mark II has set a new benchmark for videography and photography, with many new AF features made possible by the new Accelerated Capture System.
The EOS R5 Mark II has set a new benchmark for videography and photography, with many new AF features made possible by the new Accelerated Capture System. The in-camera 8K 60p RAW and 4K 120p recording with Canon Log 2 & 3 redefine the workflow for professionals.
Capture spectacular 45MP images of decisive moments with Action Priority at up to 30 fps.
AF Modes | One-Shot AF, Servo AF/ Movie Servo AF |
AF Point Selection | Spot AF, 1-point AF, Expand AF area (above/below/left/right or around), Flexible Zone AF 1 / 2 / 3, Whole area AF |
AF System Points | Up to 1053 AF frame zones |
Built-in Flash | - |
Closest Focusing Distance (cm) | - |
Continuous Shooting Speed (shots/s) (Up to) |
Mechanical shutter & Electronic 1st curtain: 12 Electronic shutter: 30 |
Digital Zoom | - |
Dimensions (Excl. Protrusions) | 138.5 × 101.2 × 93.5 |
Drive System | - |
Effective ISO |
Stills: 100–51,200 (L:50, H:102,400) Movie: Custom Picture (Off): 100–25,600 (H:32,000-51,200) Canon 709/PQ/HLG: 400–25,600 (L:100-320, H:32,000-51,200) Canon Log 2/ Canon Log 3: 800–25,600 (L:100-640, H:32,000-51,200) BT.709 Standard: 160–25,600 (L:100-125, H:32,000-51,200) |
Effective Pixels (Megapixels) | 45 |
Exposure Compensation |
±3 stops in 1/3-stop or 1/2-stop increments AEB: ±3 stops in 1/3-stop or 1/2-stop increments |
Eye Detection AF | Human and Animal eye detection (All AF mode) |
Flash Modes | - |
Focal Length (35mm Equivalent) | - |
Guide Number ISO 100m | - |
Image Resolution |
8192×5464 (JPEG L/RAW/C-RAW/HEIF) 6000×4000 (HEIF, JPEG M) 4176×2784 (HEIF, JPEG S1) 2400×1600 (HEIF, JPEG S2) |
In-body Image Stabilizer (sensor shift IS) | Yes |
LCD Monitor (Size) | 3.2 |
LCD Monitor Resolutions | 2.10 million |
Manual Focus | Yes |
Memory Card Type |
Supports 2 memory cards: • 1x CFexpress memory card (Type B compatible) • 1x SDXC/SDHC/SD (UHS-II supported) *CFexpress 2.0 and VPG400 supported *Up to 2 TB capacity supported (CFexpress card exceeding 2TB capacity is handled as 2 TB) |
Metering Mode |
Stills: Evaluative, Partial, Spot, Center-weighted average Movie: Evaluative |
Movie Digital IS | Yes |
Movie Format | MP4, CRM |
Optical Image Stabilizer | - |
Optical Zoom | - |
Optional Power |
AC Power (PD-E2 and DC Coupler DR-E6P) USB Power (PD-E1, PD-E2) |
Peripheral Connections | USB Type-C (SuperSpeed Plus USB (USB 3.2 Gen 2) equivalent), External microphone IN, Headphone terminal, HDMI micro (Type A), Remote control (N3), Sync terminal |
Processor Type | DIGIC Accelerator & DIGIC X |
Sensor Size | Full-Frame CMOS |
Shooting Modes |
Stills : Scene Intelligent Auto/Fv/P/Av/M/Tv/BULB/C1/C2/C3 Movies : Scene Intelligent Auto/P/Av/M/Tv/C1/C2/C3 |
Shutter Speed Range (s) |
Stills: Mechanical / Electronic 1st-curtain: 30 - 1/8,000 Electronic shutter: 30 - 1/32,000 Movie recording: 1/8 - 1/8,000 (Varies by frame rate) |
Silent Shutter | Yes |
Standard Power Supply | LP-E6P |
Still Image Format | JPEG, HEIF, RAW, C-RAW |
Viewfinder Coverage | 100% |
Viewfinder Type |
0.5-inch OLED, approx. 5.76million dots 59.94/119.88 fps Refresh Rate |
Weight (Including the battery and memory card) (Approx.) *For camera kits, weight includes kit lens(es). |
746 |
White Balance |
Auto (Ambience priority / White priority), Daylight, Shade, Cloudy (Effective in twilight and sunset), Tungsten light, White fluorescent light, Flash*, Custom, Color temperature setting (approx. 2,500–10,000 K) White balance shift and white balance bracketing features available *Flash color temperature information transmission possible (EX / EL Series Speedlite) |
X-sync |
Mechanical shutter: 1/200 Electronic 1st curtain: 1/250 Electronic shutter: 1/160 |
